Kia Sorento: Body Panel Gaps - Body Dimensions - Body (Interior and Exterior)Kia Sorento: Body Panel Gaps

Kia Sorento (XM, 2011-2015) Service Manual / Body (Interior and Exterior) / Body Dimensions / Body Panel Gaps

Rear Cross Member
* These dimensions indicated in this figure are actual-measurement dimensions. [ Unit : mm (inch) ]...
Exterior
...
