Kia Sorento: Erasing programmed HomeLink buttons - Mirrors - Features of your vehicleKia Sorento: Erasing programmed HomeLink buttons

Kia Sorento (XM, 2011-2015) Owner's Manual / Features of your vehicle / Mirrors / Erasing programmed HomeLink buttons

To erase the three programmed buttons (individual buttons cannot be erased):


To erase the three programmed buttons (individual buttons cannot be erased):

Press and hold the left and center buttons simultaneously, until the indicator light begins to flash (approximately 20 seconds).

Release both buttons. Do not hold for longer than 30 seconds.

HomeLink is now in the train (or learning) mode and can be programmed at any time.

Reprogramming a single HomeLink button

To program a device to HomeLink using a HomeLink button previously trained, follow these steps:

1. Press and hold the desired HomeLink button. Do NOT release until step 4 has been completed.

2. When the indicator light begins to flash slowly (after 20 seconds), position the hand-held transmitter 2-8 cm (1 to 3 inches) away from the HomeLink surface.

3. Press and hold the hand-held transmitter button (or press and
