Kia Sorento: Radiator Components
Kia Sorento (XM, 2011-2015) Service Manual / Engine Mechanical System / Cooling System / Radiator Components
| 1. Radiator 2. Radiator lower hose 3. Radiator upper hose |
4. Radiator upper air guard 5. Radiator upper mounting bracket 6. Radiator lower mounting insulator |
Never remove the radiator cap when the engine is hot. Serious scalding
could be caused by hot fluid under high pressure escaping from the radiator.
...
Coolant Refilling And Bleeding
1.
Disconnect the battery terminals.
2.
Remove the air cleaner assembly.
(Refer to Intake And Exhaust System - "Air Cleaner")
...
Radiator Removal and Installation
