Kia Sorento: Engine Room Under Cover Components
Kia Sorento (XM, 2011-2015) Service Manual / Engine Mechanical System / Engine And Transmission Assembly / Engine Room Under Cover Components
| 1. Under Cover 2. Side Cover (RH) |
3. Side Cover (LH) |
1.
Remove the engine cover (A).
2.
Install in the reverse order of removal....
Engine Cover Removal and Installation
1.
Unfasten the fasteners and bolts and then remove the engine room under
cover (A).
Tightening torque:
7.8 ~ 11.7 N.m (0.8 ~ 1.2 kgf.m, 5.7 ~ 8...
Engine Room Under Cover Removal and Installation
